Alarm
EAS 1

The RFID alarm system is superior to all competitors with superior read performance and ease of integration.

Plug and
Play

RFID Hight Reading
Performance

Small and Compact
Design

Mini
Screen

About Alarm EAS 1?

The RFID alarm system is superior to all competitors with superior read performance and ease of integration.

All settings can be updated instantly via network connection. It does not respond by automatically detecting sold products, and if an unsold product is out, it sends both audio and visual warning to the cloud server system instantly. The system installed in the floor and ceiling space is working secretly. Network etc. all log operations are saved offline on the SD card on its own. Linux operating system and advanced features and server-connected v.b. integrates easily into your software. Even at a wide door with a width of 6m and a height of 6m, it is successful. Problems such as false alarm etc. have been minimized.

Technical Features

  • Sistem Kutusu Ölçüleri Uzunluk: 25cm Genişlik:18cm Yükseklik:35cm
    Anten Ölçüleri Uzunluk: 43cm Genişlik:43cm Kalınlık: 2.5cm
    Ağırlık 1.3kg / ±0.5kg
    Gövde Materyali Plastik ve Kumaş
    Çalışma Sıcaklığı +10 ºC ile +30 ºC
    Nem 5% ile 65%
    Güç Girişi 12v
    Ürün Max Okuma Ad. 400 ad. / sn
  • RFID Protokolü GS1/EPCglobal UHF Gen2 (ISO 18000-6C)
    Çalışma Frekansı 865.6MHz – 867.6MHz
    Çıkış Gücü +10.0 to +31.5 dBm
    Max Alış Hassasiyeti -84 dBm
    Min Geri Dönüş Kaybı 10 dB
    API LLRP, C, C++, Java, and C# libraries
    Network DHCP, Static
    GPIO 4 Giriş – 4 Çıkış
    RF Çıkış Portu 2/4 Port
    Yoğun Okuma Modu Var
    Özel Alan Okuma TID, User, Reserved
  • Anten Tipi Dairesel
    Anten Kazancı 6 dBi
    Anten Ölçüleri 43cm x 43cm x 2.5cm
    Anten Frekansı 865MHz – 867MHz
    Anten Ağırlığı 0.700kg
    Anten Besleme Tipi SMA


Download Datasheet
